SLP 2/2-Way, Brass, Pilot Operated Solenoid Valve, Normally Open
SLP 2/2-Way, Brass, Pilot Operated Solenoid Valve, Normally Open
Regular price
£65.73
Regular price
Sale price
£65.73
Unit price
/
per
We have 10 in stock
Body Material: Forged Brass
Ambient Temperature: 0°C - 65°C
Fluids Temperature: 0°C - 130°C
Max. Allowable Pressure: 12kgf/cm°
Seals: EPDM
Flow as arrow, mounts in any position
Best position is solenoid vertical and upright direction.
Part Code | Size | Coil | Orifice | CV Factor | Dimensions (LxWxH) |
---|---|---|---|---|---|
SLP2DF**E1D13 | 1/2" | No Coil | 13 | 4.5 | 66x48x124 |
SLP2DF**E1D13 c/w D01-4102 | 110 VAC | ||||
SLP2DF**E1D13 c/w D01-4101A | 220 VAC | ||||
SLP2DF**E1D13 c/w D01-4106 | 24 VDC | ||||
SLP2DF**E1D13 c/w D03-5104 | 24 VAC | ||||
SLP2DF**E1E20 | 3/4" | No Coil | 20 | 7.6 | 75x58x130 |
SLP2DF**E1E20 c/w D01-4102 | 110 VAC | ||||
SLP2DF**E1E20 c/w D01-4101A | 220 VAC | ||||
SLP2DF**E1E20 c/w D01-4106 | 24 VDC | ||||
SLP2DF**E1E20 c/w D03-5104 | 24 VAC | ||||
SLP2DF**E1G25 | 1" | No Coil | 25 | 12 | 96x70x143 |
SLP2DF**E1G25 c/w D01-4102 | 110 VAC | ||||
SLP2DF**E1G25 c/w D01-4101A | 220 VAC | ||||
SLP2DF**E1G25 c/w D01-4106 | 24 VDC | ||||
SLP2DF**E1G25 c/w D03-5104 | 24 VAC |
